Phoenix LT
An advanced AI-enabled UAV system designed for long-range precision strikes with minimal operator input and maximum mission impact
Long Range Operations
Cruise-missile level performance delivered affordably — extended operational reach up to 2,000 km with robust performance in dynamic, contested, and degraded environments.
Extended Endurance
Up to 9 hours of endurance provides operators with a broad operational envelope, supporting long-duration missions, deep-strike profiles, and sustained surveillance in contested environments.
Fully Redundant Design
Built on the architecture of the most sophisticated, large-class UAV platforms, our product incorporates full redundancy across power, navigation, and critical systems. That multi-layered resilience ensures the highest safety standards in-flight and maximizes mission assurance — reliably reaching targets while minimizing false launches.
Built in AI Core
Phoenix LT redefines operational autonomy with a built-in, open AI framework that enables users or third-party integrators to create and implement mission-specific applications in-house. This capability reduces dependency, accelerates innovation cycles, and supports rapid adaptation to evolving battlefield needs.
Heavy Duty Payload Carrier
Highly versatile platform capable of delivering payloads of up to 50kg across distances of up to 2,000 km with precision and reliability.
Autonomous Traffic Management System
The Phoenix LT is equipped with an advanced onboard computer that autonomously manages UAV traffic, making real-time decisions using data from over 35 integrated sources — enabling safe and precise navigation to targets.
Multi-UAV Operation System
The streamlined launch and operations platform enables simultaneous, secure communication with unlimited UAVs, ATMS and TMS. Operators can distribute flight plans and mission data to large fleets with one command and execute multi-vehicle launches in parallel, reducing mission tempo and operator workload.
Built in AI Flight Planning
Powered by advanced AI engines, the Phoenix LT performs rapid, fully automated flight path optimization — ensuring every mission is executed along the shortest and most efficient route. The system continuously accounts for terrain elevation, ground obstacles, and airborne hazards, delivering uncompromising safety and operational precision.
Open-Source TMS
Phoenix LT empowers integrators and operators to develop custom mission applications from the ground up using the company's development platform—deploying them directly to the Targeting Management System (TMS) without OEM involvement. This unprecedented autonomy enables agile innovation and seamless integration of niche capabilities with maximum operational intimacy.
Specifications
| Max Flight Time | 9 hours |
|---|---|
| Max Speed (Vmax) | 122 Knots (60 m/s) |
| Optimized Cruise Speed (VR) | 98 Knots (50 m/s) |
| Stall speed (Vstall) | 76 Knots (38 m/s) |
| Service Ceiling | 8,000 ft. ASL |
| Optimized Operational Alt. | 2,400 ft. ASL |
| Max Pitch Angle (flight) | 15 Degrees |
| Max Pitch Angle (T.Guidance) | 70 Degrees |
| Min. Turn Radius | 450 Meters |
| Optimized Climb Rate | 5 m/s |
| Operating Temperature | -20°C to +50°C |
| Wingspan | 2,500 mm |
|---|---|
| Length | 3,500 mm |
| Empty Weight (No Fuel No WH) | 93 Kg. |
| Max Takeoff Weight | 250 Kg. |
| Max Payload | 50 Kg. |
| Fuel Capacity | 107L |
| Rocket Booster Weight | 5.3 Kg |
| Box Dimensions (Folded) | 2,800mm x 1,600mm x 1,950mm |
| Shipping Weight | 225 Kg. |
| Displacement | 550cc |
|---|---|
| Configuration | 4 Cylinders Boxer Config. |
| Fuel | MOGAS 95 |
| Alternator Output | 28V 500W |
| Start-up | Electronic built-in starter |
| RPM Range | 1,800-7,500 RPM |
| Max. Power | 50 Bhp/7,500 RPM |
| Ignition System | DC CDI Ignition System |
| Cooling Method | Air Cooled |
| Propeller Size | 2824x3418 |
| Source | GPS, Glonass, Galileo, and BeiDou |
|---|---|
| Type | HX4-06213, ZED F9P D2B |
| EW Resilience | Optional Visual Nav and Adaptive Antenna (Contact Sales) |
| RTK | Optional |
| Primary Comm. Method | 2.4G WiFi 100Mwh |
|---|---|
| Tactical Comm. (Optional) | C-Band 5.8GHz |
| Mission Comm. (Optional) | LTE |
| Power | 14KNS |
|---|---|
| Burning Time | Approx 2.3 Sec. |
| Release Mechanism | Mechanical Automatic drop-off |
| Weight | 2.5 Kg. |
Colour options
- Black
- Digital Camouflage
- Grey
- Military Camel Yellow
The Phoenix LT is a next-generation long-range UAV platform that brings cruise-missile technology into an ultra-simple operational package. Built for precision strike and persistent missions, it pairs an elastic Target Management System (TMS) with an onboard AI computer and open-access tools, allowing operators to train and adapt the system to new operational scenarios—maximizing mission fit and tactical advantage.
If your mission profile demands custom configurations or engineering adaptations, our team stands ready to deliver. Contact our sales department to discuss tailored solutions and receive a dedicated NRE (Non-Recurring Engineering) proposal designed around your specific operational needs.
